Front reach mowers for Unimog



The particular geometry of the reach mower enables a transport position with a perfect view for the operator. Similarly there is also optimum vision in the various working positions, right and/or left, always ensuring maximum operator comfort. The correct flail head rotor speed is ensured by the cast iron gear pump powered by the front PTO. The Unimog hydraulic system provides the oilflow to the reach mower cylinders. The complete unit is controlled via the single lever joystick. The reach mower has got an hydraulic break back with accumulator controlled autoreset device. The heat exchanger with thermostat was created to prevent hydraulic oil overheating even when operating in extreme and prolonged situations.

Electronic proportional controls SC TRONIK

The innovative control system is divided into two parts in order to occupy less space in the cab and consists of a proportional joystick and a control panel. The Joiystick provides four proportional functions that control the two arms movements, as well as the head rotation and the arm rotation. On the Joystick are also available press buttons to control the side shift (left to right and viceversa) of the arm holder column. The detached control panel provides press buttons to manage the rotor enagement and its quick stop (the breaking time allowed by safety criteria is 6 secondo approximately). From the control panel it is also possible to switch the breack back device from accumulator controlled autoreset device to the hydraulic break back with maximum relief valve. The EFS is also a function that can be engaged by the control panel.
The control provides the ability to select different working modes according to the type of working conditions that apply. The device also has a self-diagnostic system.

Combination with the Unimog tool carrier

The TSF600U reach mower can be combined with the Unimog tool carrier starting from the U318 model.
It is necessary to provide adequate rear ballast (further details are available from our sales network).



The Ferri TST 50U front reach mower was designed to be specifically applied to the Unimog tool holder attached to the front plate. It is made of high quality steel tubing thereby providing high strength and low weight.

Unimog Model (starting from): U218
Max horizontal reach: 4,84 m
Working width: 1,00 m
Transport width: 2,20 m



The particular geometry of the reach mower enables a transport position with a perfect view for the operator. Similarly there is also optimum vision in the various work positions. The correct flail head rotor speed is ensured by the cast iron gear pump powered by the front PTO. The Unimog hydraulic system provides the oilflow to the reach mower cylinders.
The complete unit is controlled via the single lever joystick. The reach mower has got an hydraulic break back with accumulator controlled autoreset device. The heat exchanger with thermostat was created to prevent hydraulic oil overheating even when operating in extreme and prolonged situations.

Progressive electrical controls

The joystick, positioned in the cab, enables the execution with one hand only of all operations and movements. The first part of the movement involves activation of the chosen command at 1/3 of the capacity (thus with a slow start of the manoeuvre) then, continuing with movement of the lever, the entire capacity is activated, obtaining maximum speed of movements.

Combination with the Unimog tool carrier

The TST 50U reach mower arm can be combined with the Unimog tool carrier starting from the U218 model.
It is necessary to provide adequate rear ballast. Further details from our sales network.

Floating system

Automatic and constant self-levelling on the ground of the cutting head. First arm float takes place via a nitrogen accumulator facilitate the sliding of the head on the ground.
